End Tow Planter
Built Wide. Tows Easy.
The End Tow Planter (TP Series) delivers wide planting performance with a strong bridge frame and compact end tow transport for reliable precision planting.
Key Features
Bridge frame construction provides a strong, stable working platform, while the hydraulic folding end-tow system allows for a narrower transport width in wide working width planter.
High lift capability improves clearance during operation and transport, particularly across uneven terrain.
Built using 150 × 100mm RHS construction for long-term strength and durability in demanding conditions.
Available in 2-bar or 3-bar configurations, with standard or UltraFlex frame sections to suit different farming systems.
A rotary gear flow divider accurately synchronises wheel lift and lowering for smooth, even frame movement.
Dual bead 15.5/80-24 bias ply tyres with castoring front and rear wheels provide stability and manoeuvrability in field and transport.
Available in 3m or 4m wheel centres to suit controlled traffic systems and varying farming configurations.
Optional Configurations
Rear mounted pull designed to tow an Air Cart for efficient seed and fertiliser delivery across wide planting widths.
Optional toolbox, storage cage, and handwash tank improve day-to-day usability and operator comfort.
Specifications
| Frame Type | Working Widths | Pull Configuration | Main Frame | Bar Variants | Tyres | Wheel Centres |
|---|---|---|---|---|---|---|
|
End Tow Frame |
15m – 24m |
Drawbar |
150 × 100mm RHS |
2-bar or 3-bar |
15.5/80-24 |
3m or 4m |
Row Unit Compatibility
Excel planters support a range of row unit options including:
EI853 Single Disc Row Units.
SP200 Double Disc Row Units.
CR600 Parallelogram Tyne Units.
Need help configuring a planter?
Our team can help you choose the right planter frame and row unit combination for your operation.
