Folding Frame Planter
Big Coverage. Easy Transport
The Folding Frame Planter (MP Series) provides reliable precision planting with a strong folding frame built for efficient transport and field performance.
Key Features
Vertical folding design improves transport width and manoeuvrability without compromising in-field stability.
Available with floating or fixed wing configurations to suit varying ground conditions and operating preferences.
Offered in single or double bar variants to accommodate different row spacings, layouts, and crop requirements.
Fitted with adjustable depth wheels to maintain consistent toolbar height across varying ground conditions.
Cat 3 & Cat 4 linkage pins provide secure attachment and compatibility with a wide range of tractors.
Optional Configurations
Rear mounted pull designed to tow an Air Cart for efficient seed and fertiliser delivery.
Lift assist wheels to improve transport and headland handling, reducing tractor load.
Available on 12m single bar configurations for improved transport and ground following.
Specifications
| Frame Type | Folding Design | Mounting | Available Widths | Wing Options | Frame Variants | Depth Control | Row Unit Options |
|---|---|---|---|---|---|---|---|
|
Folding Frame |
Vertical Fold |
Three Point Linkage |
9m, 12m |
Floating or Fixed |
Single Bar or Double Bar |
Adjustable depth wheels |
EI853, SP200, CR600 |
Row Unit Compatibility
The Folding Frame Planter supports a range of row unit options including:
EI853 Single Disc Row Units.
SP200 Double Disc Row Units.
CR600 Parallelogram Tyne Units.
Need help configuring a planter?
Our team can help you choose the right planter frame and row unit combination for your operation.
